OE #: 05175815AA, 68092982AA
Buttons Info: L,U,T,P,TOP,RS
*This procedure CAN ONLY be used on vehicles built in USA.
**You MUST HAVE two working programmed Remote/keys before
you can add a third remote/key.
**If you only have ONE WORKING REMOTE/KEY and want to add a
second key this procedure WILL NOT WORK.
*** Click here to Find a Locksmith in your area to program remote/key
if you only have one or none working remote/keys.
1. Using first programmed remote/key turn ignition to the ON position
for 5 seconds. (Do not crank engine). Turn remote/key off and remove.
2. Within 5 seconds insert second working programmed remote/key.
Turn ignition to the ON position (Do not crank engine) security light
will begin to flash and chime will be heard within 10 seconds. Turn
remote/key off and remove. NOTE: Some vehicles will not chime,
only the security light will flash.
3. Within 5 seconds insert third NEW CUT remote/key and turn ignition to
the ON position (Do not crank engine). The security light should start
flashing and within 10 seconds you should hear a chime and the
security light should go out. Once the security light goes out, the new
remote/key should be programmed. Turn remote/key to the OFF
position, remove key.
4. Test key and remote.
